LDP (OD/CB) – for Bass
Low/High Gain Overdrive
Boost
LOW DOWN PRESSURE
• For BASS
• Overdrive - Clean Boost
• 100% handcrafted in Germany • 3 year warranty
Player:
Marcus Miller, Victor Wooten, Stanley Clarke, Tim Levebvre ...
Other companies need a lot of buttons for a good sound, we only need 3 for each overdrive pedal and 2 for the clean boost pedal. From slightly distorted bass with tube sound character to completely distorted - no problem for the LDP (OD/CB). The overdrive pedal has a deep boost (toggle switche) to push the lower frequencies without getting muddy. The clean boost with deep boost (toggle switch) gives a lot of pressure to the sound and up to +20 dB (toggle switch) output level. From sweet to neutral to funky, the clean boost active tone control does it all. Two completely different sounds => one pedal for a professional bass sound.
LDP (OD/CB) = LOW DOWN PRESSURE
__________________________________________________________________________________________________
RODENBERG LDP (OD/CB)
Overdrive / Clean Boost for Bass
LDP = LOW DOWN PRESSURE
• Two completely separate pedals, Overdrive and Clean Boost in one box
• Overdrive with two toggle switches for deep boost and gain boost
• Controls: Level, Drive, Tone
• Clean Boost with two toggle switches for deep boost and +20dB output level boost
• Controls: Level, Tone
• Signal path: Bass => Overdrive => Clean Boost => amplifier
• Jewel LED: Overdrive = blue, Clean Boost = green
• 2x foot switches: Mechanically true bypass, (almost) no switching noises
• Input and output: 6.3mm jack
• Power supply via 9-18 V power supply unit (not included, no battery operation)
• Handcrafted in small quantities
• Made in Germany
• 3 year warranty
Victor Wooten / Uli Rodenberg
(Picture by RODENBERG amplification)
Stanley Clarke / Uli Rodenberg
(Picture by RODENBERG amplification)
Marcus Miller / Uli Rodenberg
(Picture by RODENBERG amplification)
Tim Lefebvre / Uli Rodenberg
(Picture by RODENBERG amplification)
Power supply
• Mains adapter plug socket 5.5 x 2.1 mm, negative pole inside
• Power supply via 9-18 V power supply unit (not included, no battery operation)
• Current draw: 9-18V / 50-80 mA
Technical specifications::
Input level: -20dB
Input impedance: 500kOhm
Output impedance: 10kOhm
Dimensions
• Dimensions ( L / D / H ): 3.7 x 4.7 x 1.3 ( inch )
• Weight: 1.1 lbs
